The main aim of installing marine rubber fender is to protect both the vessel and the dock from major failure during the berthing period. External forces, such as abrasion or other natural factors can possibly occur during the berthing process. Therefore, marine rubber fenders are made to solve this problem, and therefore, more money can be saved due to less vessel or dock fixing.

Rubber fenders are designed to absorb the energy that a vessel transfers to a berthing structure, hence the term energy absorption, so that the amount of energy received by the dock is much less compared to when fenders are absent. The force that is bounced back and relieved by the dock through the fender is called reaction force. A good quality marine fender can be determined by measuring the energy absorption and reaction force. A good quality marine fender has a high energy absorption and the low reaction force, hence the reduced impact yielded from the vessel to the dock, as well as the minimized impact bounced back from the dock to vessel.

There are a lot of fender types that can be used on the port, for instance: cylindrical fender, V-type, A-type, M-type, super cell, and super cone fender. Tugboat fenders, however, are installed on tugboats to protect vessels from major failure in the incidence of a crash. In order to achieve the best result, there are several factors that to consider in choosing the right type of marine rubber fender, namely the dimension of berthing vessels, the type of the port, situation around the port and the existence tugboat to guide the vessel while berthing.

1. Vessel dimensions

Vessel dimensions, in terms of type and dead weight tonnage, become significant factors in choosing not only the right fender type, but also the size of the fender. The larger the vessel, the larger the required fenders will be. Usually, fenders which are equipped by frontal frames are chosen as they have large contact area. From the economical perspective, V-type fender can be one of the options. However, to yield the maximum result, super cell and super cone fender are selected. For the ports that are used for the small to medium vessel, the type A, V, M, LMD or cylindrical are chosen to protect the port wall.

2. Type of the port

Another significant factor that can influence in choosing the right type of fender is the type of the port. Based on the location and position of the port, there are several port structures that are usually used including dolphin, monopile, jetty and quay wall. In the dolphin terminal, the terminal consists of poles that are used for vessels to berth. Rubber fender that is usually used in this terminal is super cell fender. However, jetty terminal, which is also known as floating terminal, does not need a really tough construction as it floats. This terminal is used for passenger ships. Unlike other kinds of ports, terminals with quay wall consists of concrete structure which parallels the beach. Large vessels cannot berth on this terminal due to the shallow waters in which the terminals are usually located.

3. Marine environment

The marine environment, such as high and low tides of the seawater, the power of wind which influences the waves, is another factor that needs to be considered in choosing the right fender type and dimension. If there is a big difference between the high and low tides, elongated fenders must be chosen, especially when the port is used by diversely sized vessels. If a small vessel needs to berth during the low tide, it can still berth to this port. Therefore, it is recommended to have the fenders installed in vertical position. On the other hand, when the sea is windy and wavy, the water also gets rough. This causes vessels to bump into the port wall. Elongated V type fender, super cell or super cone fender equipped by frontal frames can be used for this type of port.

4. The availability of guidance during berthing process

The availability of tugboats during the berthing process is very important in order to avoid vessels from crashing into the port wall. This is because the speed of the vessel and the berthing angle can be adjusted as the vessel moves closer to the port.

Warehouse storage shelves are the basic storage equipment of the cargo transfer station, in warehousing management has an important role, to properly preserve the integrity of the goods. Storage shelves set up seven principles of custody, the goods can be properly kept:

1, for the channel for custody. In order to facilitate the goods out of storage, easy to move in the warehouse, the basic conditions for the goods for the channel custody.

2, as far as possible to the height of the code, improve storage efficiency. Effective use of the volume of the library should be put to the height of the code, in order to prevent damage, to ensure safety, should be used as much as possible scaffolding and other storage equipment.

3, according to the selected frequency of the location of the library. Goods that are shipped and purchased in high frequency should be placed near the entrance, easy to work; the poorly placed items are located far from the entrances and exits; seasonal items are selected according to their seasonal characteristics.

4, the same species in the same place custody. In order to improve the efficiency and efficiency of the operation, the same item or the like should be kept in the same place, and the familiarity of the employee with the place of placing the item in the store has a direct impact on the time of entry and exit, placing the similar item in the neighboring place and improving the efficiency an important method.

5, according to the weight of goods arranged custody position. When placing a place, heavy items are placed underneath, and light items are placed on top of the shelves. Need to manually carry the large items are based on the height of the waist. Sichuan warehouse shelves said to improve efficiency, to ensure safety is an important principle.

6, according to the shape of the arrangements for storage methods. It is also important to keep the goods in accordance with the shape of the items, such as the standard goods should be placed on the tray or shelf custody.

7, according to the principle of first-in first-out. Preservation of an important one is for perishable, easy to break, easy to corrupt items; for the function of easy to degenerate, aging items, as far as possible according to the principle of ancestors first to speed up the turnover. Because the diversification of goods, personalization, the principle of short life is very important.

For more professional knowledge, please visit the official website of sanji-first.com.

Web guide technology has developed rapidly in recent years. Thanks to the high-performance automatic web guide control system, the edge position controller ensures that the materials will not deviate from the correct position. The position of the coil is always be tracked during the production process with real-time web guiding without any manual intervention, which ensures and improves the quality and efficiency of the products.

Characteristics Of The Web Guide System

1. Driven by brushless servo motor, maintenance-free

2. Precision ball screw

3. Large guide stroke

4. The length and span of the guide roller can be customized

5. The mesh material which is the most difficult to detect, also be easily controlled

Professional Web Guide System Manufacturer – Arise

Arise is a professional web guide system manufacturer, located in Chongqing, China and it focuses on the research, development and production of the position sensors, web guiding system, and tension system including photoelectric, CCD, color sensitivity, and ultrasonic. The products are widely used in steel, no-woven fabric, corrugated paper, textile, printing, labeling, plastic film, building materials, cables, rubber, tires, etc. The web guide equipment provided by Arise will ensure that your machine runs normally at full speed. The automatic guide system can ensure continuous, accurate control of various types of materials in various production processes, and limit waste and downtime to a minimum.

YSmarines has introduced the marine mooring chock which is a mooring system that is designed to support safe and reliable moorings of all types and purposes through its patented low friction technology.

The transition from steel wire rope to fiber rope is widespread across industry. Fiber rope has a good strength to weight ratio and ease of handling, resulting in much lower risk of injury.

Although advantageous, a major weakness of fiber rope is poor resistance to external abuse and abrasion through everyday operations and poor surface contact. Abrasion continues to be one of the most common root causes of rope failure and reduction in its residual strength.

It is impossible for synthetic rope to perform to its maximum capabilities when used with poorly maintained deck equipment, often rusted or with a rough surface finish. Rope manufacturers recommend surfaces are correctly prepared, maintained and routinely inspected before and after rope installation. A 300-microinch (7.62-microns) finish is recommended for all deck hardware which comes into contact with the rope, in addition to the avoidance of chocks heavily scored from previous wire rope use.

The YSmarines marine mooring chock is said to provide vessels with the ability to be moored with greater safety, performance, and efficiency.

The marine mooring technology is said to provide vessels with the ability to be moored with greater safety, performance and efficiency, offering multiple benefits. The marine mooring chock is versatile and capable of being fitted to brand new vessels and retro fitted to existing chocks and panama fairleads with no hot works or dry docking required.

Increased safety is a feature of the marine mooring chock which reduces rope wear and abrasion, reducing the risk of breaking or failure. There is also no need for crew members to be near mooring lines under tension, as minimal (if any) chafe protection is required following installation of the new system.

The marine mooring chock’s smooth surface and finish and its material characteristics provides better equalization of mooring loads, especially when in high swell. The self-lubricating, low friction marine mooring chock material requires little or no maintenance and no painting, coating or external protection. Corrosion resistant materials technology is featured on the new system, providing protection against the arduous environments faced in the global maritime industry.

Custom manufactured from initial chemistry to end product, the marine mooring chock is available for use on all chock and vessel sizes. Developed to optimize and enhance vessel moorings, much of the advantages derive from the unique materials technology developed through over 20 years of field experience in design, testing and material selection with fiber ropes.

The featured materials technology in YSmarines marine mooring chocks allows for the accommodation of HMPE fiber rope with a lower risk of abrasion and wear when in contact with the Panama chock. The marine mooring chock is also suitable for polyester/polypropylene, polyester and nylon ropes, as required for FLNG, FSRU, and STS where a specific synthetic pennant may pass through the fairlead. In all cases, due care and attention are required in relation to the loads involved, chock designs, and rope sizes.

Web guide control refers to the technical operation for the coil materials and must always keep the edge of the coils neat and consistent during the spraying, printing, punching, laminating, slitting, or other coil winding processes. Once the edges of the coils are not aligned, it will cause errors in subsequent steps, resulting in material waste. Therefore, when processing coils, it is necessary to do the correct deviations in time for the offset coils. The whole process is called web guiding. The equipment, which is used for the whole process, constitutes a set of web guide system. A typical system includes a controller, a sensor, a guide mechanism and a driver.
The importance of the web guiding system
The flexo printing machine often adopts an automatic web guide system to ensure the stable horizontal position of the printing material before entering the printing unit. It can detect the deviation of a certain horizontal edge position of the printing material and correct it in time, with an accuracy of ±0.5 mm. Generally, for opaque materials, such as paper and aluminum foil, photoelectric sensors are often used, for transparent materials, such as films, ultrasonic sensors are used. Once the printing material enters the printing area and die-cutting rewinding area, the stability of its horizontal edge position is guaranteed by the installation accuracy of the own processing machine and the parallelism between the rollers
The working principle of the web guiding system
The web guide control system is a closed-loop controller. First, the sensor detects the edge or line of the coil, and the system automatically reads the deviation of the actual position and setting the position of the coil and converts the offset into an electrical signal. They send the signal to the controller. After that the signal is calibrated by the controller, it is outputted to the linear driver. The linear driver drives the deviation correction according to the magnitude of the signal. Then the guide mechanism adjusts the coil to the set position. The drive signal of the current drive is only proportional to the deviation of the coil, which makes it possible to provide precise control for various coils.
Applications of the web guiding system
The web guide system covers a wide range of applications and is essential in various industries such as packaging, printing, labels, building materials, paper pulp, non-woven fabrics, and corrugated paper processing.

For more professional knowledge, please visit the article page of web edge guiding system.

A marine searchlight is one of the handiest marine accessories to have aboard. It can help you find a navigation aid or landmark in the dark. A searchlight can also help you find things dropped in the water — if the thing floats, or the water is shallow and clear. It can also be a safety aid, used to signal for help or warn other boats of a hazard in the water. Here’s what to look for in a marine searchlight, whether for your existing boat or as an ­option aboard a boat you are buying.

Installing a searchlight in a Boat

The particulars of the installation have a large impact on a permanently installed searchlight. For instance, a light mounted on a hardtop is convenient to install and may even allow the use of a light that can be aimed manually. However, a light beam shooting over the white bow of a boat often creates a bloom of hazy light that impedes the skipper’s ability to see. If you are set on a top-mounted light, temporarily wire the light and have a helper hold it on your top while the boat is stationary at night so you can check whether this will be a problem for you. Mounting the light forward is preferable. Just be careful about searchlight rail mounts.

Many boat rails vibrate while the boat is underway. This vibration might not seem excessive for a rail, and mostly, it isn’t. But we have observed numerous boats aboard which a small vibration in the rail resulted in a huge vibration to the light’s beam, making it difficult to aim and keep on a target. For this reason, we suggest you favor a light mounted directly to the deck.

Hand-Held searchlights for Boats

Some hand-held searchlights are wired. These connect to a cigarette-lighter receptacle. If you choose this type, consider buying a quality receptacle that locks the male plug from the light. You’ll have to cut off the plug that came with the light and splice in the new locking plug, a simple DIY task. A locking plug and receptacle prevents the light’s cord from pulling out inadvertently in use — a thing that can happen at the worst moment. Also, consider installing auxiliary receptacles at other places from which you might use the light. These include at the bow, on the flying bridge, and in the engine compartment.

Other hand-held searchlights are battery-operated. These provide the freedom to move around the boat without the restrictions of a cord. Of course, unlike wired lights, which have power as long as your boat’s batteries are charged or the engine is running, a hand-held light’s batteries tend to go dead at exactly the same time a wired light’s cord tends to get pulled out of its nonlocking receptacle. Charging vigilance is required for the boater who owns a battery-operated searchlight.

With either type, make sure you select a hand-held searchlight that is heavily armored with rubber or plastic because, as sure as the tide, you will drop it. I also like lights with a brow or rim that extends beyond the lens. This not only adds shock protection but also cuts down glare and helps preserve night vision. Pick the best searchlight for your boat. A marine boat searchlight is vital for boating at night.

For more information about other various types of boat lighting at night, please visit the page of marine lighting.

Sanji-first strives to manufacture innovative various kinds of tool storage with high-grade materials and supports this commitment with professional representation and consistent, superior service to meet the different requirements of the customers.

Plastic Parts Box

The plastic boxes are used for the storage of small parts. It can be used together with a tool cabinet and workbench etc. There are three colors of yellow, blue and red. The boxes also are suitable for heavy-duty. One-piece industrial strength boxes are rust, water and corrosion-proof. Full-width hanger lip supports heavy loads when suspended from hanging rails or louvered panels. The reinforced side-rib design adds strength and prevents spreading when stacked. The products improve material handling efficiency in virtually any industry. Sanji-first provides high-quality plastic parts boxes with modest prices, which can help optimize storage space and improve parts protection.

Tool Storage Box

The tool storage box also can be sold separately. It has two types including CNC toolbox BT type including BT30, BT40, BT50, BT60 and CNC toolbox HSK type including HSK50, HSK63, HSK100. It is made of advanced punching pp material with the high life. It can be easily fitted into the bracket by screws. It is suitable for tools for cylindrical shanks. The color is red. It can accommodate different tool holders. It can help saves space and spend the least time to find with easy to see at a glance. It has double reinforcement around with super bearing. It has a porous position with large storage and less land occupation.

Tool Storage Sheath

Thetool storage sheath is used for BT30, BT40 and BT45. It is applicable to all kinds of tool cart. It is suitable for machining center of the factory workshop, warehouse handling, storage, a knife to protect all kinds of knives, a knife with easy handling and safety.It is made of ABS material with the feature of anti-slip. It has centralized management with access to convenient, improving efficiency. Different cutting tool set can be placed in collocation. The tool storage sheath manufactured by Sanji provides the perfect solution for tool storage, offering professional storage in inserts specially optimized for your machining and cutting tools. Tools are stored in a space-saving and organized way and are always within reach and ready for use. The advanced production equipment is creating durable products for long service life.

Tool Storage Holder

The tool storage holder for CNC tool to fulfil the daily practice. The storage accessibility of tools affects the cost-effectiveness of modern machine tools. It has two series. CNC tool holder BT series is for the storage of BT30, BT40, BT50 and BT60.The HSK series ones for the storage of HSK50, HSK63 and HSK100. The tool holder bracket accommodates every size of CNC tool holder. The cutting tools inserted into tool holders & these tool holder brackets, which are fitted into Different CNC trolleys, CNC racks and CNC tool cabinet. It is designed with a steel sheet and has 2 handles to easy carrying. Sanji-first provides a wide range of choices for the organization and storage of tool and can offer customer best quality tool storage holders with high standard materials, protection and security promised.

The mask machine is used to produce various masks with certain filtering performance through a series of processes including hot pressing, folding and forming, ultrasonic welding, waste removal, ear belt and nose strip welding of multi-layer non-woven fabric. In the production of masks, multiple layers of materials must be neatly bonded together, otherwise waster or even jams will occur. The web guiding system can achieve multi-layer material alignment, no waste in the refueling process, and the jam never occur. The web guide is a selectable position controller for tracking the edge of the material or printing lines for high-accuracy swing.

How does the web guide machine work

The web guide machine is a position deviation control of the thin material during the conveying process by the motor at a constant speed. If winding speed of the material needs to be changed, the correction speed cannot be changed, which will easily lead to the phenomenon that the curling cannot be corrected. And the microcomputer photoelectric deviation correction web guiding system can meet customers’ needs.

The web guide can be used in flat mask machines. The system includes a computer-controlled photoelectric correction controller, color discrimination tracking photoelectric, ball screw, and synchronous motor. The MCU control used by the computer-controlled photoelectric correction system has a frequency conversion output, which can adjust the motor speed according to the needs. The structure is simple, easy to operate, convenient and practical in production.

1.Track the edge of the substrate, correct the the unevenness of the substrate when winding.

2. Track the edge of the substrate to keep the coating material equidistant from the edge.

3.According to roll speeds of different materials , the correction speed can be adjusted to keep balance with it.

Characteristics of web guiding system

1. Driven by brushless servo motor, maintenance-free

2. Precision ball screw

3. The length and span of the guide roller can be customized

4. The material which most difficult to detect , can also be easily controlled.

7. The tracking speed can be adjusted arbitrarily without changing the size of the belt shaft.

8. Feedback function of the semi-fast voltage and electric current , can automatically restore and protect the internal circuit system, with good stability and quick action response.

High-performance Arise web guiding system for mask machine

Arise is an audited, leading web guiding system manufacturer in China with a professional R & D team. Using the high precision web guiding equipment supplied by Arise, can ensure continuous and accurate edge position control of multi-layer non-woven fabric in various production processes and make mask machine runs normally at full speed.

For more professional knowledge about the web guiding system, please visit the page of web guiding articles.

Coil materials refer to long-sized continuous materials such as paper, film, sheet, non-woven fabric, metal foil, silk, thread, etc. In the process of uncoiling, technological processing, winding, etc, deviation of the coil materials may occur, due to the deviation of the coil itself or the processing machine. The web guiding control system provides a solution to reduce the occurrence of such situations. The system always tracks the position of the coil material during the production and makes corrections in real-time. It can ensure and improve the quality and efficiency of production.

Working principle of web guiding

The web guiding is to guide the sensor to emit infrared or ultrasonic to monitor the operation of the coil material and send a signal to the controller. After that the controller finds that the web has a positional deviation, according to the preset command by the controller, the controller controls the drive system to swing to correct the web position.

The web guide system uses brushless DC servo motor drive, precision ball screw driv with, compact structure, good mechanical rigidity, low inertia, suitable for high-speed and high-precision web guiding.

The system is composed of a controller, a sensor, an electric driver, and a correction guide mechanism. The sensor detects the edge position of the coil material and reads the deviation between the actual position and the set position, converting the deviation into a voltage signal proportional to it. Then sends this signal to the controller. After the signal is amplified and calibrated by the controller, the signal is output to the electric driver, and the electric driver drives the guide mechanism to perform correction actions according to the magnitude of the input signal to guide the coil material to the preset position.

Technical parameters of the web guiding system

1. Support three working methods of line tracking, edge tracking, centering tracking, etc

2. Support photoelectric sensor, ultrasonic sensor, CCD sensor

3. Automatic detection of sensor parameters, no need to calibrate the sensor in most environments

4. Automatic stroke measurement without mechanical limit switch

5. Ultra-high speed response speed with 500 microseconds (0.5 milliseconds)

6. The DC servo motor drives the ball screw

7. Store 10 groups of different material parameters, convenient and fast to switch materials

8. Simplified Chinese/Traditional Chinese/English three-language menu operation

9. Humanized operation, quick and easy

10. Support PLC/human-machine interface networking control

Main applications of the web guide system

The web guide system has been widely used in the applications of various industries and it is essential in industries such as packaging, printing, labels, building materials, paper pulp, metal processing, non-woven fabrics, corrugated paper processing, etc.

Tire rubber industry: molding machine, carcass cord, laminating drum common template correction, inner liner pre-correction, film blowing machine, industrial belt laminating machine.

Packaging, printing and paper industries: satellite web printing machine, bump plate printing press machine, inspection machine , slitting rewinder, coating machine, etc.

Battery industry: lithium battery coating machine, lithium battery slitting machine, lithium battery rolling die machine, battery stacking machine.

Web guide system expert – Arise

Arise is a professional web guide system manufacturer in China and Arise web guiding can ensure continuous, precise control of various coil materials in various production processes. With the high-performance automatic Arise web guide control system, it can ensure that the material will not deviate from the correct position and reduce the waste, downtime to a minimum.

YSmarines is one of the leading suppliers of lights to the marine and offshore markets and has years of experience providing marine lights including floodlight for safe areas, searchlights, navigation lights, to recreational boat owners and boating professionals, from interior and exterior incandescent and LED marine lighting is to replace bulbs. Where traditional aquaculture lighting relies on filament lamps to provide illumination, LED technology provides a solid state solution offering superior energy efficiency, running life and reliability without compromising performance.

Originating from a commercial LED luminaire manufacturing background, YSmarines has worked closely with local salmon farms to develop energy-efficient alternatives to the aging filament-based lighting products. The submersible LED fish penlight is set to revolutionize livestock pen illumination by reducing operational and maintenance costs, whilst increasing reliability and productivity.

The clients of the YSmarines, have experienced a significant reduction in operation costs since deploying the submersible LED fish pen lights. Particularly those utilising remote fuel powered generator sets, where transportation of fuel is costly and often dangerous. Similarly, maintenance costs are reduced by removing the need to replace fragile glass lamps.

Information on LED marine lighting products can be found at ysmarines.com.
