XYMJ provides customized tungsten carbide dies. Tungsten carbide has excellent hardness, wear&corrosion resistance, resistance and small expansion coefficient, which increase the service life. The life time of carbide dies is ten times or even dozens of times than the steel dies. XYMJ can provide various types, which including cold heading dies, cold punching dies, wire drawing dies, hexagon dies, spiral dies, etc.

Factors To Consider For Designing Carbide Dies

1. It must have a high yield, good structural shape with high dimensional accuracy.

2. If necessary, all the bottom and upper of the carbide dies should use tungsten carbide through the analysis of the most worn parts. In some cases, you can adopt tool steel and tungsten carbide in combination under the situation that has punch difficulty processing or fixed in order that the mould manufacturing and application must be the most reasonable and economical.

3.Under the allowed processing conditions of tungsten carbide die, the mosaic structure is more economical, easy to process and repair.

Tungsten Carbide Punch Dies

The carbide punch manufactured by XYMJ has excellent performance, outside diameter, inner diameter, the height of which, are all accurate grinding, tolerance within 0.01mm.

Features

1.Well abrasion Resistance.

2. High Hardness, around 88HRA or even 91HRA.

3. A high compressive strength is greater than 6000MPa.

4. Excellent corrosion Resistance.

5. High precision and high quality, the service life is over 10 times longer than common high-speed steel.

6. A low coefficient of thermal expansion

Tungsten Carbide Wire Drawing Dies

Tungsten carbide wire drawing dies are made from 100% virgin material of WC and Co. It has good wear resistance, high bending strength. It is a good economical choice for steel wire and other large-size wire drawing applications. It is applied for drawing wire, tubes, rod, type as S11, WTA. S13 ect, used for wire drawing of steel, aluminum wire and copper wire.

Advantages Of XYMJ Tungsten Carbide Wire Drawing Dies

1. excellent wear-resistance, adopting GB class A cemented carbide mould core with strength over 2200N/mm 3.

2. More wire rods can be drawn: the size is 20% longer than common mould, which makes XYMJ carbide wire drawing dies can work longer.

3. Tightening connected with the steel jacket: adopting advanced cold bushing technology and interference bushing craft. They are tightening connected with the steel jacket.

XYMJ manufactures tungsten carbide products with 100% virgin material with high stability and high performance. All carbide products manufactured by XYMJ meet the ISO quality standard. Also, skillful workers and advanced equipment enable XYMJ to have the ability to provide all kinds of customized carbide parts. XYMJ take great efforts to increase quality rather than quantity to promote the flexibility of competing in the world market. Always satisfying customers, providing them with high quality and grade product as well the service is our aim.

Tungsten Carbide Strips

The main composition of tungsten carbide strips is tungsten powders and cobalt powders. It has have many excellent characteristics such as high hardness and strength, good wear and corrosion resistance and very stability under high temperature, widely used in many fields such as woodworking, machining of refractory alloys, stainless steel, high manganese steel, for processing cast iron, non-ferrous metal and aluminum section bar, etc. XYMJ has various types including carbide strips with more than 300mm, carbide strips with angle, STB blanks with US Standard, etc.

Tungsten Carbide Rod

Carbide rods can be used for making end mills, various drill bits, automobile special cutter, engine special cutters, horology, processing special cutters, integral vertical milling cutter, graver and etc. Also, the tungsten carbide rod can be made into hard alloy punches, mandrels, centers, and perforation tools.

Features

(1) Good wear resistance, higher toughness, high precision, better deformation and fracture resistance.

(2) Advanced automatic extrusion equipment to produce.

(3) HIP sintering and precision grinding to ensure have good performance.

(4) Both blank and finished conditions available.

(5) Can reach a mirror effect surface after accurate grinding and polishing.

Tungsten Carbide Plate

Carbide plate has high hardness, good abrasion resistance and toughness, heat and corrosion resistance. It is widely used in the following fields:

1. The production of cast iron rolls and high chrome roll knife.

2. Suitable for the production of discharge plate, stamping die, cold punching die, such as electronic stamping die.

3. Used in the production of copper, aluminum, stainless steel, cold rolled sheet, El board, Q195, SPCC, siliconsteel plate, metal, standard parts, upper and lower punch and otther high-speed mold.

4. Wear resistance of tungsten carbide plate is higher, suitable for hardwood, logs, aluminum, copper rods, cast ironiron processing for the production of various types of motors, electronic into the mold, stamping electronic mold.

XYMJ is a professional tungsten carbide supplier for carbide mould/dies and all kinds of customized wear parts. Which integrates research & development, production, marketing and services.Our company was founded in 1999 and located in Zigong City,Sichuan province,China. We have more than 20 years experience in researching and manufacturing of tungsten carbide products such as carbide molds & dies, bushings, valve seats, nozzles, inserts & cutting tools, carbide rods and bars, carbide plates & strips and other customized tungsten carbide wear parts etc.

We can produce various products as per customers special requirements. OEM/ODM is welcomed. With high-tech equipment and strict quality test system, We have won a good reputation of high quality in both domestic and overseas markets.

Our tungsten carbide products have been exported to many countries around the world. Being reliable and professional is our value of service. Providing customers with high satisfaction services and high quality products is always our mission. Sincerely welcome the friends all over the world to contact us for WIN-WIN cooperation!

Tungsten carbide blanks production

Good quality carbide products rely on 100% virgin raw materials and advanced wet-milling,pressing machines and sintering furnaces. We put emphasize on every production process of our carbide blanks. To keep good quality of carbide blanks is the base of furtherly machined high precision finished carbide parts.

Finished products machining

XYMJ owns a series of high-precision grind machines, including flat grinding machines, OD and ID machines, Centerless grinding machines and customized grinders. Also we have CNC machines, EDM, Wire-cutting machines and drilling machines etc. With our skilled workers, we can control very high precision of each carbide part.

Inspection and testing process

In order to ensure the quality of all our tungsten carbide finished products, a very strict QC management system has been introduced. With our advanced inspection equipment and our professional inspectors, we are able to do raw materials inspection, on-site inspection and after finishing inspection to ensure 100% good quality of your carbide products.

Packaging and Shipping

Special-designed packing boxes and tubes will be used properly for the standard and customized carbide products to ensure the safety of the goods during the transportation process. A wide range of shipping ways can be available for your shipments, for example we can ship goods by Sea, by air and by Express companies like DHL/FedEx/UPS/TNT/Aramex etc.

When adopting high function and high-speed molds for production, the mold is required to have a long service life. In recent years, high-precision and high reliability are required even if for a small amount of production. Carbide dies with high durability will be the best choice.

Tungsten carbide wire drawing dies have the following features which ensure the high durability

1. Strong power resistance

The mold should be given a very large extrusion, bending stress, impact and other messy loads during the extrusion process. Therefore, the material selected will have high power resistance after heat treatment. The mold material should have outstanding hardenability to ensure that the mold can be hardened and uniform.

2.Excellent wear resistance

The mold should have high wear resistance to ensure normal service life and produce large quantities of extruded parts. In general, the hardness of steel is proportional to wear resistance under certain conditions. Therefore, mold materials must have sufficient hardenability. In addition to the hardness, The decisive factors are the thickness, composition, amount of excess for the matrix after heat treatment and the amount, size, type, dispersion, red hardness of carbide. The tungsten carbide has a content of more than 80% of WC, the wear resistance of which is several times higher than steel. So to get a long service life for the drawing mold, and carbide is mostly adopted for the materials.

3.Sufficient thermal stability

For continuous production, the temperature of the mold sometimes will reach 200 ° C, which will reduce the strength and hardness, so that the mold material should have outstanding thermal stability. Carbide drawing dies have sufficient thermal stability for high-temperature resistance.

4.Excellent processability

Cold extrusion mold has a long manufacturing time with high accuracy requirements. Usually, it is necessary to cast, cutting, heat treatment, grinding or other fine finishing. So only the materials that have good processability can meet the production needs. The excellent process of carbide molds will be the best choice.

Tungsten carbide wire drawing dies have high hardness, excellent thermal stability, high durability and long service life and are one of the best mold materials.

Carbide wire drawing dies adopt high-quality tungsten carbide as the core, which has high hardness, good thermal conductivity and low friction coefficient. Tungsten carbide wire drawing dies are simple to produce with corrosion-resistant, impact-resistant, and low cost which is the outstanding feature of this product. It is suitable for the drawing of ferrous metals, large-size wires, and occasions with poor wire drawing conditions.

The Brands And Applications Of Tungsten Carbide Wire Drawing Dies

Wire drawing is the manufacturing process for reducing or changing the cross-section of the metal wire by using a series of stretched plates or molds. Carbide wire drawing die is a kind of tungsten carbide dies with wide applications in various fields.

Brands: YG6X

Applications

Suitable for the production of carbide dies with drawing inner holes which are smaller than ¢ 6.00mm.

Brands: YG6

Applications

Used for the non-ferrous metal round bar which has drawing inner holes that are smaller than ¢ 20mm and the drawing dies which has inner holes that are smaller than ¢ 10mm.

Brands: YG8, YG10

Applied for drawing steel and the production of non-ferrous metal round bars & pipes.

Brands: YG15

Used for the drawing of steel rod and pipe which have a high shrinkage.

The Precautions And Maintenance Of Tungsten Carbide Wire Drawing Dies

1. Ensure the stability of the drawing machine

Each drawing drum, over-line guides should be smooth, flexible, strictly controlled for beating tolerance. If the drum is found, the guide wheel has a worn trench and the drawing dies should be repaired in time.

2.Good lubrication

Good lubrication is important to ensure the surface quality of the wire and extend the service life of the mold. The lubrication index should be checked frequently, removing the copper powder, impurities in the lubricant, so that the equipment hole can not be polluted. If the lubrication doesn’t work, it must be replaced in time and clean it.

3. Reasonable allotype

Reasonable allotype is to ensure the surface quality of the wire and control size accuracy, reducing the wear of wire drawing drum and equipment operating load. For sliding wire drawing machines, it is necessary to familiarize with the mechanical elongation of the equipment. The sliding coefficient is reasonably selected, which is the primary step of fitting mold.

4. Appropriate adjustment of the size for the compression angle

The surface reduction rate of each drawing and the material of the drawn wire are also closely correlated with the compression angle of the respective mold. The size of the compression angle is appropriately adjusted according to the size of the surface reduction rate.

5.The timely replacement of the aging drawing dies

When the drawing die reaches the service life, please replace it in time for repairing treatment to avoid excessive causing scrap the wire.

For more professional knowledge, please visit the article page of high quality tungsten carbide wire drawing dies.

Tungsten carbide is widely used in various industries due to its unique high hardness and strong wear resistance. What are its common applications?

1.Cutting tools

Tungsten carbide can be used as a variety of cutting tools. Because of its high hardness and strong resist compression performance, tungsten carbide is one of the best material choices for cutting tools. The tungsten carbide cutting tools include carbide drill bits, small circular saw blades, carbide rotary burr and so on. As the material of cutting tools is the most widely used field for tungsten carbide.

2. Mining tools

The cemented carbide for mining accounts for about 30% of the total tungsten carbide production. Thanks to the high hardness, strong impact toughness, outstanding bending strength and excellent wear resistance, carbide mining tools are usually applied in geological exploration drill bits, roller cone drills and coal cutters for petroleum and gas fields, engineering excavation road tools, percussion drilling in the building materials industry.

3. Tungsten steel mold material

Under normal circumstances, the proportion used in the manufacturing of various molds accounts for about 8%, which includes carbide drawing dies, cold heading dies, cold punching dies, cold extrusion dies, hot forging dies and drawing mandrels. Usually, the cemented carbide applied for making molds is selected from medium and high cobalt, coarse grain grades.

4. Wear parts

The tungsten carbide wear parts include carbide nozzles, carbide balls, tungsten carbide valve seat & valve sleeves, carbide tire cleats, carbide guide rails and so on.

5. Structural parts

The carbide structural parts include rotating seal ring, lathe head, grinding machine spindle, bearing, etc, which can effectively solve the problems of mechanical seal ring thermal cracks.

Trustworthy Tungsten Carbide Manufacturer – XYMJ

XYMJ has focused on the production and processing of tungsten carbide products for more than 20 years, the products including carbide dies, bushings, valve seats, inserts & cutting tools, carbide rods and bars, carbide plates & strips and other customized tungsten carbide wear parts. It has superb blank forming and precision machining capabilities with high performance and a low-cost advantage. It has a grinding machine for smooth finish, frosted finish, concave finish, and convex finish, which can better satisfy customer’s requests.

High performance of tungsten carbide, in addition to high hardness, there are also excellent wear resistance, corrosion resistance, high-temperature resistance, etc and can be used as cutting tools, mining tools, wear parts, etc, which are also the reasons for wide applications in various industries.

Tungsten carbide is an alloy which has the main components of tungsten carbide powder with metal bender. It is widely used for manufacturing high-speed carbide cutting tools for hard, tough materials. The high-performance tungsten carbide has excellent characteristics.

of hard, tough materials. The high-performance tungsten carbide has excellent characteristics.

1. High hardness and excellent wear resistance

The hardness of cemented carbide can reach 86 to 93HRA, which is equivalent to 69 to 81HRC. High hardness can be maintained at 900-1000 ℃ with excellent wear resistance. Compared to high-speed steel, the cutting speed can be 4-7 times higher with 5-8 times service life, which can cut hard material with a hardness of 50 HRC.

2.High strength and high elastic modulus

The tungsten carbide has a compressive strength of up to 6000 MPa and an elastic modulus (4 ~ 7) × 105 MPa, which both are higher than high-speed steel. However, its bending strength is low, typically 1000 ~ 3000MPa.

3. Excellent corrosion resistance and oxidation resistance

It is generally resistant to atmospheric, acid, alkali and is not easy to oxidize. There is a wide range of applications in the industries of fluid and chemical, such as various valves used for fluid control including regulating valves, black water valves, lock slag valves, and decompression noise reduction valves, etc.

4.Small linear expansion coefficient

When the tungsten carbide products are working, the shape size the stable

5.The finished products are no longer processed with re-grinding

Due to the high hardness and brittleness, the powder metallurgical formation is no longer cutting or re-grinding, and when the demand is re-processing, it can adopt electric sparks, line cutting, electrolytic grinding and other electric processing or special grinding wheel cutting. It is usually used by a certain specification paper made of cemented carbide, adopting brazing, bonding or mechanical clamping for the blade body or mold.

How To Improve The Performance Of Tungsten Carbide

In order to adapt to the harsh environment under different working conditions, tungsten carbide often needs to be reprocessed to make corresponding changes for the original performance, so what are the methods to change the performance of tungsten carbide?

1. Improve the quality of raw materials

Improve the purity of raw materials

High-strength, high-impact toughness alloys have high requirements for the purity of raw materials, while continuous cutting tool with low impact load but high machining accuracy, have low requirements for raw material purity.

Control the particle size and distribution of raw materials

It should avoid excessively large particles in the carbide or cobalt powder raw materials, and prevent the tungsten carbide from forming coarse carbide grains and cobalt pools during sintering.

At the same time, the size and composition of the particle materials should be controlled to meet the needs of different products. For example, carbide cutting tools should adopt tungsten carbide powder with a fisher particle size of less than 2 microns, wear-resistant tools should use tungsten carbide powder with a particle size of 2-3 microns, and mining tools should adopt tungsten carbide powder with the particle size of larger than 3 microns.

2. Improve the structure of the tungsten carbide

3. Improve or select new hard phase and binder phase

The performance of tungsten carbide is affected by the composition and structure of the hard phase and the binder phase. Generally speaking, when the content of the hard phase is high and the grains are finer, the hardness is high and the wear resistance is good, with poor impact resistance. Improving the hard phase and the binder phase is one method to change the performance.

4. Surface hardening treatment

To solve the contradiction between wear resistance and toughness, hardness & strength of tungsten carbide, surface hardening treatment can be adopted.

The coating is physically or chemically depositing a layer of TiC or TiN on the surface of the cemented carbide to increase the wear resistance. The most rapid development at present is the coated tungsten carbide.

5. Add elements or compounds

6. Heat treatment

For more useful knowledge, please visit the article page of high peformance tungsten carbide
