The hardware part of the drilling simulation training system is highly simulated on-site real equipment. Various panel layouts, operation methods, parameter display methods, etc., are consistent with the production site.

The system combines advanced computer industrial control technology, artificial intelligence technology, scientific visualization technology, virtual reality technology and advanced network technology, as well as strict simulation of the actual process of drilling engineering, and adopts high-reliability classic physical and mathematical models to provide users with the following Various training operations such as drilling, drilling, well control, equipment fault detection, and handling of drilling accidents and complicated situations.

The three-dimensional graphics synchronized with the operating conditions will be projected on the front screen to produce a visual effect similar to that of the scene, accompanied by realistic sound effects of the on-site equipment environment, giving people an immersive sense of immersion and realism.

The advanced software system can create corresponding snapshots based on real on-site well conditions and history information, so as to conduct highly simulated on-site training operations for trainees. The non-sequential driller operation mode breaks the fixed operation mode that the previous training exercises must be done step by step, so that the trainees can operate arbitrarily based on the snapshot. The drilling simulator realizes a high degree of simulation from well conditions to equipment operation, which greatly improves the operational flexibility of the trainees, and greatly improves the training efficiency and training effect of the trainees.

Programs Of Drilling Simulation Training

1. trip module

(1) Normal trip in operation

(2) Operation in case of resistance when trip in

(3) Normal trip out operation

(4) Operation in the event of stuck drilling

2. Drilling module

(1) Normal drilling and picking upstand (single)

(2) Normal drilling and drilling with bouncing bit

(3) Drilling in low-pressure formation

3. Downhole accident processing module

(1) Judging and treatment of wall sticking

(2) Judging and treatment of sand settling

(3) Judging and treatment of balling up

(4) Judging and treatment of hole collapse

(5) Judging and treatment of key seating

(6) Judging and treatment of hole shrinking

(7) Well immersion (gas immersion, brine immersion)

(8) Fishing tap

(9) Junk milling

4. Shut-in operation

(1) Shutting in operation when overflow occurs while drilling

(2) Shutting in operation when overflow occurs while tripping in and out

(3) Stripping after shutting in when overflow occurs while tripping out

(4) Shutting in operation when overflow occurs while tripping in and out collar

(5) Shutting in operation when overflow occurs in barren hole

5. Cementing operation

(1) Running casing

(2) Drilling out plug

(3) Cementing

Bolts are cylindrical threaded fasteners. Usually, the bolt is composed of a thread area, a shaft area, and a head area. There is only a part of the threaded area, followed by the unthreaded area. A fully threaded bolt is a bolt without a shaft. Partially threaded bolts are ordinary bolts, and is not fully threaded, but only a part. So, Which is better between the two types of bolts.

What are full-threaded bolts?

Fully threaded bolts are generally shorter in length. The thread length of such bolts is equal to the length of the bolt, with threads running through the entire length of the bolt from the head to the end.

What are partially threaded bolts?

Where longer bolts are required, the thread length does not need to be too long. Therefore, in the production of standard parts, only a part of the threads on the long bolts are processed to save processing costs. Partially threaded bolts have an unthreaded portion under the head, this unthreaded portion is called the grip length, and this is the partially threaded bolt. Due to the large force of many connectors, the half-threaded part is on the outside of the joint of the workpiece, while the inner part of the force is smooth without threads, which can improve the mechanical strength of the bolt and help to withstand greater torque.

Why Choose Full Thread Bolts?

If clamping strength is of greatest interest and alignment and shear strength are less of an interest, then fully threaded bolts may be an option. A fully threaded bolt means that all the tension applied to the bolt is distributed over the entire structure, which means it can handle more force than a partially threaded bolt. Full threaded bolts are used in environments that rarely require shear and tend not to loosen much. Once installed, a fully threaded bolt spreads pressure along its entire length, with the greatest holding pressure at the head where it meets the material being held.

Why Choose Partially Threaded Bolts?

The length of the non-threaded portion of a partially threaded bolt can vary depending on the specific application of the bolt. When using partially threaded bolts, the unthreaded portion can be brought into the threaded hole as part of the bolt-through application. Nuts and washers are threaded on the ends.

Partially threaded bolts are best used where alignment and shear resistance is important. The grip length of the bolt can provide the required alignment. When your project requires a lot of force to hold things in place, partially threaded bolts can provide the required resistance. The unthreaded portion is also referred to as the “grip length” and does not include weak points that can lead to shearing. This is because there are no threads in the grip length and no weak points that could lead to cracking or bending. So in order to shear such a bolt, a huge force is usually required.

How To Choose

When choosing a fully threaded bolt vs a partially threaded bolt, consider whether you need a maximum grip or maximum shear protection. If you need a grip, find the correct full-threaded bolt made of the material you need. If you are more concerned about shearing, choose a partially threaded bolt that will help prevent shearing.

Different partially threaded bolts have different grip lengths, so consider choosing a specific grip length before purchasing.

One of the easiest ways to get this information is to ask a fastener expert to help you. If you buy bolts from KENENG, it shouldn’t be very difficult because the people we hire are very knowledgeable about these things.

Subsea oil and onshore oil are essentially the same, both are liquid to semi-solid mixtures of hydrocarbons (organic substances, mainly alkanes, naphthenes, and aromatics). Oil on land can also be divided into marine crude oil and continental crude oil. Marine crude oil is formed from organic matter in ancient oceans, while continental crude oil is formed in lakes on ancient land.

Exploring and developing oil and gas in the ocean is the focus of modern marine geological exploration. It requires a large drill ship or platform to load drilling equipment to drill on the coast or offshore.

Drilling ships can be divided into single body and double body (suitable for water depth of 30-200 meters).

Platforms include bottom-mounted (suitable for water depths less than 30 meters) and pile-inserted (suitable for water depths of about 90 meters) fixed platforms, as well as semi-submersible floating platforms (suitable for water depths greater than 200 meters), which can be selected according to actual needs.

What is the Difference Between Offshore Oil Drilling and Land Drilling?

1. The composition of organic matter and the ratio of some chemical elements in offshore oil are different from those in continental oil.

2. In terms of exploitation, the exploitation of land crude oil and seabed crude oil is different. Conventional crude oil on land is relatively easy to exploit, while the exploitation of seabed crude oil involves more complex processes, including platform construction, drilling, and pipeline laying, which are different from land oil exploitation.

One is how to erect the derrick stably above the water surface and withstand the attack of wind and waves.

The second is how to build a special wellhead device between the turntable and the seabed to isolate the seawater from the wellbore.

Third, there are fewer vertical wells and more inclined wells in offshore drilling, so there must be offshore drilling platforms that can ensure the normal operation of drilling rigs and other drilling equipment.

3. The cost of offshore drilling is high, about 3 to 10 times higher than that of land drilling.

Chengdu Esimtech Petroleum Equipment Simulation Technology Co., Ltd. is based on the Sichuan Provincial Department of Education Petroleum Engineering Computer Simulation Technology Key Laboratory. Esimtech is a company engaged in scientific research, design, production, maintenance, sales and computer application technology in the field of oil and gas industry An integrated high-tech enterprise.

Esimtech is committed to the development of simulation and simulation systems for petroleum engineering and petroleum equipment, and has achieved a series of application results with completely independent intellectual property rights, continuously providing users with the best products and creating value for users. After more than 20 years of persistence and unremitting efforts, it has successively developed petroleum engineering such as drilling, well control, logging, oil production, gas production, downhole operations, oil and gas gathering and transportation, fracturing and acidizing, drilling rig installation, coiled tubing, and snubbing operations. Training simulation system, the product line covers the complete field of oil and gas industry application sites. In addition, the drilling simulator is constantly updated and the technology is becoming more and more mature. It has become recognized by the industry as the drilling simulator product with the most complete functions, the best performance and the most reasonable price at home and abroad.

The drilling simulator can mainly carry out simulation training of drilling technology, simulation training of drilling accident handling, and simulation training of well control technology. This article introduces 2 drilling simulators manufactured by Esimtech, including full-sized drilling simulator and portable srilling well control simulator, which are suitable for drilling simulator training in oil companies, oil schools, training centers, etc.

Full-sized Drilling Simulator

Full-sized Drilling Simulator training content:

1. Novice operation learning

2. Shut in the well

3. Well killing

4. The complex situation of underground accidents

5. Rig installation

Features of Full-sized Drilling Simulator equipment software:

1. Fully complies with IADC and IWCF well control specifications

2. Full 3D animation

3. Realistic live sound effects

4. The hardware and software structure conforms to the training characteristics: one-key start, one-key shutdown, remote monitoring

Portable Drilling Well Control Simulator

Training content of portable drilling well control simulator:

1. Shut-in operation

2. Killing operation

Features of portable drilling well control simulator equipment software:

1. The simulation training system complies with IADC and IWCF standards.

2. It is easy to carry, has complete functions, has real and reasonable well control process simulation, and can flexibly set various drilling parameters, such as drilling tool structure, well body structure, formation parameters, equipment parameters, etc.

3. Three-dimensional, interactive animation.

4 Fully intelligent scoring, fair and just assessment.

5 Fully adopt industrial grade components, the system is stable and reliable.

Esimtech produces training simulators for various types of work in the oil and gas industry. After more than 20 years of unremitting efforts, it has successively developed a number of petroleum engineering training simulation systems represented by oil drilling simulators.

With the well intervention simulator to carry out the training of well intervention operation and well intervention snubbing operation, many difficulties in the training work can be solved. Below we will introduce several well intervention simulators produced by Esimtech in detail.

What is Well Intervention?

Well intervention refers to an operation of oil drilling and subsequent oil well maintenance. It is a maintenance and maintenance measure taken to ensure the smooth use of oil wells.

What is Well Intervention Snubbing Operation?

Using special well intervention equipment, under the condition of pressure on the wellhead of oil, gas, and water wells, it is a downhole operation technology to implement pipe and rod tripping, wellbore repair, and production stimulation measures.

What is the Significance of the Well Intervention Snubbing Operation?

Protect oil and gas formations

Protective sleeve

Improve single-well production

Ensure construction safety and environmental protection

The well intervention snubbing operation solves the technical problems in the well intervention process of oilfield development and is a leap forward in the well intervention technology.

5 Types of Well Intervention Simulator

Snubbing Simulator (MR)

Snubbing simulator (MR) combines full-size drilling snubbing simulator with VR technology. Enable trainees to complete training items such as running and pulling tubing, tools, etc. in a training environment that combines virtual and reality, and master basic forced tripping operations and common forced tripping technical processes.

ESIM-FCT1L Full Size Coiled Tubing Simulator

ESIM-FCT1L Full Size Coiled Tubing Simulator is equipped with an operation console and displays the operation scene through 3D animation. And you can freely set related parameters and operation sequences. The simulator is capable of training on well intervention, well logging, stimulation, drilling, accident handling, etc.

ESIM-PSS2 Portable Snubbing Simulator

The parameter settings and panel layout of the ESIM-PSS2 Portable Snubbing Simulator are the same as those of the actual equipment, similar to the device on-site.

Through the operation process designed according to the actual program, 3D interactive animation, and realistic sound simulation, it provides training for forced tripping technicians in oilfields.

ESIM-FSS2 Full Size Snubbing Simulator

ESIM-FSS2 Full Size Snubbing Simulator presents downhole tool movement through 3D animation and provides training operations such as pulling and running tubing, tools, etc.

The Snubbing Simulator combines petroleum engineering technology, computer technology, virtual reality technology, and realistic environmental sound effects to enable trainees to be trained in an immersive environment.

ESIM-PCT1 Portable Coiled Tubing Simulator

The portable coiled tubing simulator provides training items such as drilling bridge plug, sand-washing, fluid flowing by gas-lift, problem treatment, etc. It is mainly used to train new staff, coiled tubing operators, coiled tubing operation team leaders, and more.

The simulator can solve basic methods of operating coiled tubing, common technology processes of coiled tubing operation, common troubles and problems by combining accurate mathematical models and physical models, highly realistic 3D scene display, computer network technology, and customized software and hardware treatment, etc. and other issues.

Esimtech has developed relevant training simulation systems for petroleum engineering industries such as snubbing operations, drilling, well control, logging, oil production, gas production, downhole operations, oil and gas gathering and transportation, fracturing and acidizing, drilling rig installation, and coiled tubing. You view more knowledge on the articles of what is well intervention simulator.

The tension control system plays a very important role in the production of coil materials, such as high-speed gravure printing machine, laminating machine, coating machine, slitting machine and other equipment, are basically equipped with advanced tension control system, which mainly controls the tension of paper, plastic film and other reel materials. The tension control plays an important role in keeping the tension constant. In the production process, if the tension is too large, it will lead to tensile deformation of the material. If the tension is too small, the stress deformation between the material layers will easily occur, resulting in irregular winding, which will have a direct impact on the quality of the final product.

In order to ensure the smooth operation of the tension control system and maintain the optimal tension of the coil material, it is necessary to fully understand the tension control system. This article mainly tells the control modes, composition and working principle of the tension control system.

Control Modes Of Tension Control System

The main control modes of tension control system include direct tension control and indirect tension control.

Direct tension control is also called feedback control. It adopts tension sensor to detect the actual tension, and then converts the measured value into feedback signal and compares it with the preset tension. When there is a deviation between the two, the tension controller gives the corresponding control of the tension control system to match the actual tension with the preset tension, thus forming a tension closed-loop system. Direct tension control does not need to consider various adjustments and compensations, and can eliminate steady-state errors with high control accuracy.

Indirect tension control, also known as compensation control, can adjust and compensate the parameters that affect the tension stability to avoid the tension changes that will occur and indirectly maintain the tension stability. Compared with direct tension control, indirect tension control has poor randomness and low control accuracy.

Structure And Working Principle Of Tension Control System

The tension control system is mainly composed of three parts, which includes unwinding tension control system, traction tension control system and winding tension control system. The constant tension control of the coil material is realized through tension sensor, tension controller, frequency conversion controller, magnetic powder brake and other components.

1. Unwinding tension control system

Working principle

The tension sensor detects the actual value of the unwinding tension and feeds it back to the tension controller. Compared with the preset value of the unwinding tension in the tension controller, the deviation between the two is calculated by PID and the control voltage is output to control the resistance moment of the magnetic powder brake acting on the unwinding shaft, so as to achieve the purpose of adjusting the unwinding tension.

2. Traction tension control system

Working principle

In the production process, when the traction tension of the coil material changes, the swing roller will make corresponding swing amount. At this time, the high-precision potentiometer will indirectly measure the change of the traction tension, and then feed back the corresponding signal to the traction roller driver. After the PID adjustment, the operation speed of the traction roller will be controlled. The swing amount of the swing roller will be adjusted by changing the pressure of the low-friction cylinder to keep it stable at the set position, that is, the traction tension control will be realized.

3.Winding tension control system

Working principle

The tension control system detects the actual value of the winding tension through the tension sensor, and then feeds it back to the winding web tension controller. Compared with the preset value, the deviation between the two is calculated by PID and the control voltage is output to the winding motor driver to adjust the running speed of the winding motor to achieve constant tension control. In the winding tension control system of some equipment, the taper tension control system is often added, which can make the coil material in the state of tight inside and loose outside during the winding process, so as to prevent the slipping among layers of the coil materials and improve the tension stability of the subsequent procedures.

Oil and gas gathering and transportation simulation system is a training system with advanced technology and complete functions in China, which can meet the actual needs of oilfield training. It has the ability to conduct simulation training for gathering oil and gas & oil and gas transportation.

Advantages of Oil and Gas Storage and Transportation Simulator

1. The oil and gas storage and transportation simulator is the product of a collection of petroleum engineering, oil and gas storage and transportation and computer technology, computer simulation technology, and virtual reality technology.

2. Based on the national occupational technical standards and occupational skill appraisal standards of various types of work in the field of oil and gas gathering and transportation, and combined with the actual situation on site. Using the electronic sand table, process board, and touch screen as the medium, the application of computer, virtual reality, and other technical means. Real simulation of the entire process of oil and gas storage and transportation from the wellhead to the combined station, to the oil depot, and then to the oil and gas export.

3. It can simulate the collection of oil well products, gas-liquid separation, crude oil dehydration, crude oil stabilization, sewage treatment, oil and gas storage and transportation, and other main process links, process flow, and process equipment.

4. The system consists of a combined station, long-distance crude oil transportation, natural gas pressurized and sub-transport, LNG receiving station, refined oil depot, and supporting software.

The appearance of each operation console in the system is basically the same as that of the real equipment on site.

The layout, operation mode and parameter display of various equipment panels are basically consistent with the on-site situation.

The hardware system is designed in accordance with industrial standards, and the data acquisition and control system is composed of PLC, which ensures the reliability of the equipment to the greatest extent.

The system input cost and maintenance cost are low, and there is no security risk.

5. The system calculates the pressure, flow, and temperature of the fluid in the pipeline in real-time. Advanced mathematical models make training more realistic in the field. The process status is displayed on the large-screen LCD TV, making the whole process clear and easy to understand, which can reduce the training time of the trainees and allow the trainees to have a deeper understanding.

Training Content of the Oil and Gas Storage and Transportation Simulator?

1. The simulation training system can realize the operation simulation training for the technicians of the five major parts of the joint station, the long-distance crude oil pipeline pumping station, the pressurized sub-transportation station, the oil depot, and the LNG terminal.

2. It enables students to understand the internal structure, principle, and usage of various oil and gas gathering and transportation equipment, be familiar with the typical stations and processes of this part and be able to deal with common accidents on site.

Characteristics of Oil and Gas Storage and Transportation Simulator

1. The appearance and structure of the field equipment and facilities are highly simulated, and are made according to a certain scale.

2. Simulation of the operation of oil and gas gathering and transportation system can be realized.

3. The electronic sand table displays the equipment pipeline and layout of each link in the oil and gas gathering and transportation process.

4. The three-dimensional animation shows the structure and working principle of the main equipment in the oil and gas gathering and transportation process.

5. Use the touch screen and virtual reality technology to meet real process requirements.

Tension control refers to the ability to control the tension of raw materials when they are transported on the equipment. The tension control of slitting machine must be effective for any running speed, including the acceleration speed, deceleration speed and uniform speed of the machine. Even in case of emergency shutdown, it shall be able to ensure that the cut raw materials are not scratched or damaged.

Why Tension Control Is ImportantIn The Slitting Machine

With the increasing degree of mechanization, the requirements for the efficiency of winding operation are also higher and higher. When the slitting machine is applied to the slitting operation of film, tape and paper, the large reel of the whole roll can be divided into several small reels according to different requirements to meet the needs of different occasions. The tension control system is the core part of the slitting machine.

The tension control of the slitting machine is basically manual tension control and automatic tension control. Manual tension control is to control the tension by adjusting the manual power supply device by the operator when the coil diameter changes to a certain stage during the winding or unwinding process.

Full-automatic tension control is to measure the actual tension value of the material belt directly by the tension sensor, and then convert the tension data into a tension signal and feed it back to the tension controller. By comparing this signal with the preset tension value of the controller, the control signal is calculated. The automatic control execution unit makes the actual tension value equal to the preset tension value, so as to achieve the purpose of stabilizing the tension.

The stability of tension control is directly related to the quality of slitting products. If the tension is insufficient, the raw material will loose or drift during operation, and the finished material will wrinkle after slitting and rewinding. If the tension is too large, the raw material is easy to be broken, resulting in more broken ends of the finished material after slitting and rewinding.

Tension Control Of The Slitting Machine

The formation of tension can be realized in many ways, but its basic principles are consistent. During the startup process, the linear speed of the winding coil is greater than the linear speed of the unwinding coil to generate a certain tension in the winding roll. When the winding reaches the appropriate tension required by us, timely adjust the power mechanism to stabilize the linear speed of the winding coil and the unwinding coil, so that the raw material can operate stably under this tension. The tension control system is to meet the tension stability of the whole machine.

Tension Control Detection System Of The Slitting Machine

1. Tension sensor detection

It is a direct detection of tension, which is closely combined with machinery, and is equipped with a detection method of moving parts. Usually two sensors are used in pairs, and they are installed on the end shafts on both sides of the detection guide roller. By detecting the applied load on both sides of the guide roller, the material belt makes the tension sensor sensitive element produce displacement or deformation, thus detecting the actual tension value, converting this tension data into a tension signal to feed back to the tension controller.

2. Indirect tension detection system of floating roll

A set of floating roll is installed in front of the tracking roll. The position of the floating roll is detected by a potentiometer. The tension control method is to maintain the constant tension by maintaining the position of the floating roll unchanged.

3. Magnetic particle clutch

Magnetic particle clutch is used to control the rotational torque of the input take-up roll to achieve tension control: the magnetic particle clutch is composed of the driving part and the driven part, and is connected with the take-up roll through the universal coupling and other transmission mechanisms, and the middle is filled with fine iron particles as the torque transmission medium.

A magnetic field is formed by applying a certain current to the excitation coil, and the magnetic particle is magnetized. The magnetized magnetic particles attract each other and form a chain arrangement. When the driving part rotates at a constant speed, the coupling force between the magnetic particles is destroyed and a circumferential tangential force is formed. The product of the tangential force and the radius of the magnetic particle circle is the rotational torque of the driven part for winding up, so as to realize the coupling of the output torque from the driving part to the driven part in continuous rotation, thus achieving the purpose of tension control.

4. The slitting & unwinding capacity and speed tension detection system

It mainly uses magnetic particle brake to control the unwinding speed. Its working principle is that the magnetic particle brake is equipped with a coupling, as well as input parts and output parts with magnetic coils. Below the magnetic coil is an annular groove, and below the groove is an annular rotor, namely the output part. The annular groove is located in the center of the output part, and the groove is filled with magnetic powder.

When there is excitation current in the magnetic coil, the coil will generate magnetic flux to make the magnetic particles arranged along the magnetic field direction, which will generate damping between the input part and the output part and transfer the torque. If the tension and speed applied on the aluminum foil are increased or decreased, the tension and speed can be effectively controlled by changing the magnitude of the excitation current, or the current or voltage value applied by the amplifier to the coupling coil.

These oil and gas animation training systems can three-dimensionalize various operations and equipment in the oil and gas industry, and express various working principles and design principles in the form of three-dimensional and visual animations.

Oil and Gas Production Process Animation

This oil and gas production animation includes the production process of oil and gas. Including the working principle of the equipment from the wellhead to the gas gathering station and the oil gathering station, as well as production and maintenance.

The oil and gas production process animation is displayed through three-dimensional sections and multiple perspectives, which enables students to quickly master the use of various equipment in the process of oil and gas production, and effectively improves training efficiency.

Oil and Gas Drilling Animation

There are two main types of oil and gas drilling animations produced by Esimtech. Including the disassembly and assembly and working principle of drilling and well control equipment animation, and well control animation.

Animation of disassembly and working principle of drilling and well control equipment

The animation of disassembly and assembly and working principle of drilling and well control equipment is to train the internal structure, disassembly and assembly and working principle of drilling and well control equipment and tools in the form of animation.

What is the function of the animation of the disassembly and assembly of drilling and well control equipment and its working principle?

1. Familiarize students with the composition and principles of drilling and well control equipment and tools.

2. Master the inspection and debugging of the main working systems of drilling and well control equipment and tools.

3. Can analyze and judge the working conditions of drilling and well control equipment and tools, and analyze and troubleshoot in time.

Well Control Animation

Among them, the well control animation shows the installation and use of different types of well control equipment and the well control operation process in the form of animation. The equipment, operations, and scenes in the animation are all made according to the real situation of the scene.

Oil and Gas Technology Animation

The oil and gas technology animation produced by Esimtech includes land drilling rig assembly animation, downhole tool disassembly and working principle animation, diesel engine disassembly and assembly animation, logging animation, HSE animation, and so on.

Land Rig Assembly Animation

The land drilling rig installation animation includes the whole process from the drawing of the baseline diagram, to the installation of each object in the middle, and finally to the completion of the entire derrick lifting. All the processes are displayed according to the actual installation process, including the installation process of 198 components in total. From watching the animation, you can quickly, clearly, and completely understand the whole process of the installation and lifting of the entire land drilling rig.

Downhole tool disassembly and working principle animation

The animation shows the internal structure of the tool and the composition of its parts in the form of an exploded diagram and shows the internal structure of the tool in the form of a half-section or semi-transparent shell. The disassembly and installation steps and working principle of the tool are shown in the form of animation, and the text and dubbing are used to explain.

Diesel engine disassembly animation

The internal structure and main components of the diesel engine and its components are displayed in the form of exploded diagrams. Demonstrate the disassembly, inspection, maintenance, and working principle of the diesel engines in the form of animation, and explain with text and dubbing.

It can make the students familiar with the working principle of diesel engines, and master the inspection and debugging of the main working system of diesel engines.

Well logging animation

The logging animation includes the appearance, logging principles and uses of various logging instruments such as compensated neutron logging, conventional resistivity logging, dual laterolog, spontaneous potential logging, natural gamma ray logging, etc. And contains the operation method of instrument connection.

The animation intuitively explains the principle of the instrument through three-dimensional perspective, section, and panorama display methods. It can deepen the impression of the students, so as to quickly master the logging principles and the use of various instruments.

As an oil and gas animation company, Esimtech can produce animations including drilling and well control equipment disassembly and working principle animation, land drilling rig assembly animation, downhole tool disassembly and working principle animation, well control animation, diesel engine disassembly and assembly animation, well logging animation, oil and gas production animation, HSE animation and other types. We are able to meet the different needs of different clients, if the mentioned types are not what you need, you can also contact Esimtech for more animation types.

Esimtech’s emergency simulation related products are emergency virtual simulation solutions for typical oil and gas accidents. The purpose is to enable students to develop emergency response skills and related psychological qualities through virtual reality interaction and immersive experience. Emergency simulation training system Using VR is developed based on the emergency training software platform. Through VR interaction, immersive experience, and systematic training and testing, trainees can complete the training of emergency pre-judgment, emergency handling, and emergency escape, and cultivate their psychological quality.

Drilling Emergency Practice Training Platform

Drilling refers to the project of using special equipment to establish oil well channels on the ground and underground so that the underground oil and gas can be collected along the oil pipeline to the ground for use. Drilling plays a very important role in various tasks of oil exploration and oilfield development, and the risk is relatively high. Therefore, the development of oil and gas simulation training in drilling is necessary.

The simulation in the oil and gas industry includes a variety of accidents that can occur during drilling.

Emergency treatment and escape when blowout is out of control

Emergency treatment and escape in the event of fire and explosion

Emergency treatment and escape in case of H2S leakage and poisoning

Comprehensive deduction

emergency handling skills

Through the virtual simulation, the trainees can deeply remember the emergency handling process, overcome the pressure and take correct emergency handling measures when encountering an actual accident.

Drilling Emergency Exercise Simulation Training System

The oil and gas training simulators offer individual and multi-person exercises. The training process performance of the trainee can be used to evaluate the trainee’s operation, and the completion of the task and the problems and errors in the trainee’s operation can also be displayed. The system can be used as an operator training simulator-oil and gas to train drilling workers in emergency handling and rescue capabilities.

The drilling emergency exercise simulation training system realizes the simulation and three-dimensional interactive operation of the drilling scene, drilling equipment and facilities, environment and personnel conditions, accident occurrence and progress, and personnel emergency treatment process. The system can carry out simulation training on emergency handling of typical drilling accidents.

Esimtech has obtained patents in China and internationally, and has been a member of IADC and IWCF. If you want to know more about oil and gas training simulators, you can always contact us. Or there is no product you need in the product list. If you want to customize it according to your actual situation, we can also provide corresponding services.
